Let’s take an in-depth look at the Chauvet Professional Maverick MK Pyxis moving light. We’re going to walk you through some of the key features of this light that will help bring your events to life.
Quick Answer: We love the Chauvet Maverick MK Pyxis for its independent inner and outer rings, infinite pan and tilt, and animated outer ring of LEDs. It’s a light that’s sure to wow and entertain your guests.
Chauvet Maverick MK Pyxis Overview
If we had to pick a favorite from our lighting inventory, it would have to be the Chauvet Maverick MK Pyxis.
Why do we love it? Let’s start with our 3 favorite features.
- Independent outer light ring
9 x 15 W RGBW LEDs form an outer ring around a central 60 W RGBW LED, which can be operated independently. - Animated outer light ring
There are countless ways to animate the 9 LEDs on the Maverick’s outer ring. The only limit is your creativity. - Infinite Pan/Tilt
Most lighting fixtures can only pan 540° and tilt 230°. The Maverick just keeps going.
Maverick MK Pyxis Connections
The Chauvet Maverick is set up for both wired and wireless operation with a variety of connections for power and lighting data.
- PowerCON True 1 in and out
You can daisy chain up to 4 of these lights on a single 15 A circuit. - 3- and 5-pin DMX in and out
- Network in and out
Compatible with multiple network formats, including Art-Net, sACN, and Kling-Net. - Wireless DMX
- RDM
Allows remote setting of fixture mode and address by RDM enabled consoles.
Using The Chauvet Maverick MK Pyxis
There is a nice big color display on the front of the fixture, which is super helpful for setting the mode on the fixture itself.
We typically run the Maverick in 26 channel mode, but it can be set all the way up to 131 channel mode if you need more advanced features and effects.
Maverick MK Pyxis Specs
DMX Channels Single Mode: | 26,66,113,131 |
DMX Channels Dual Mode – Function: | 13,26,33 |
DMX Channels Dual Mode – Pixel: | 30,40,80 |
DMX/Network Connectors: | 3- and 5-pin XLR/Amphenol XLR Net RJ45 |
Light Source: | 9 LEDs outer ring (quad-color RGBW) 15 W, (1.29 A), 50,000 hours life expectancy |
Light Source: | 1 LED center pixel (quad-color RGBW) 60 W, (4.5 A), 50,000 hours life expectancy |
Strobe Rate: | 0 to 20 Hz |
Beam Angle (Center/Outer): | 2.7°/4.9° to 32° |
Field Angle (Center/Outer): | 4.5°/7.9° to 47.8° |
Zoom Range: | 4.9° to 58.4° |
Illuminance – Center: | 19,306 lux @ 5 m |
Illuminance – Outer: | (7.9°) 4,724 lux @ 5 m, (47.8°) 437 lux @ 5 m |
Power Linking: | 4 units @ 120 V; 8 units @ 208 V; 9 units @ 230 V |
Weight: | 31.96 lb (14.5 kg) |
Size: | 12.20 x 8.85 x 18 in (310 x 225 x 459 mm) |
Color Temperature: | 2,800 to 10,000 K |
